Towerbühne TVG R®28
| TVG R28 | |||
| 28x14 | 28x14 | ||
| Tower | Tower | 10 | 8 |
| Arcs | Arcs | 3 | 2 |
| Area | Total stage area without loadingdock & ramps | 49,73 x 24,83 m | 49,73 x 24,83 m |
| Performance area | 26,12 x 21,76 m | 26,12 x 21,76 m | |
| Roof overhang | 3,00 m | 3,00 m | |
| Wings | Wings | 11,00 m | 11,00 m |
| Outer tower | 10,18 m | 10,18 m | |
| Centre | 9,36 m | 9,36 m | |
| Inner tower | 5,15 m | 3,96 m | |
| Clearance | Clearance | 15,00 m | 15,00 m |
| Clearance centre arc | 16,84 m | 16,84 m | |
| Clearance extra high | 16,50 m | 16,50 m | |
| Clearance extra high centre arc | 18,34 m | 18,34 m | |
| Stage floor | Stage floor height | 2,35 - 2,65 m | 2,35 - 2,65 m |
| Backstorage | 6 m Backstorage | optional | optional |
| Rigging | Total rigging capacity depending on load distribution | 96,3 t | 74,3 t |
| Rigging capacity performance area depending on load distribution | 67,5 t | 45,5 t | |
| Rigging capacity per wing | 10,6 t | 10,6 t | |
| Rigging capacity per outrigger / main PA | 3,8 t | 3,8 t | |
